Description
The 3M Scotch-Brite 900-06 mandrel is the arbor used to mount a Scotch-Brite unitized wheel on a drill or die grinder. Its 6 mm shank clamps in the machine's collet or chuck.
Specifications
- Use: mounting Scotch-Brite unitized wheels.
- Shank: 6 mm.
- Material: steel.
- Maximum speed: 6,500 rpm, according to 3M.
What it is for
Unitized wheels, such as the Scotch-Brite EXL, have a centre bore and cannot be fitted directly into a collet. The mandrel clamps them between two flanges and centres them on the axis. Its small size gives access to small or complex parts.
Speed, a safety point
The maximum speed of the assembly is the lower of the two speeds shown: that of the wheel and that of the mandrel. With this mandrel, do not exceed 6,500 rpm, even if the wheel accepts more. Many die grinders run much faster: you then need a variable-speed or suitable machine.
Mounting
Clamp the wheel firmly between the flanges, without crushing the non-woven. Check that the wheel runs true before working: run-out makes the tool vibrate and wears the wheel unevenly. Clamp the shank fully into the collet.
See also our unitized wheels, our die grinders and our 3M products.
Quick order
All references for this product. Indicate your quantities and add everything to the cart at once.
| Ref. | Width | Diameter (mm) | Bore | Availability | Price | Quantity | |
|---|---|---|---|---|---|---|---|
| 13 / Standard / 6 mm | 3M_7000038377 | 13 | Standard | 6 mm | On order | €13,70 | |
| Standard / 50 / M6 | 3M_7000046309 | Standard | 50 | M6 | In stock | €11,00 | |
| Standard / Standard / Standard (ref. 7000038378) | 3M_7000038378 | Standard | Standard | Standard (ref. 7000038378) | On order | €18,54 | |
| Standard / Standard / Standard (ref. 7100101327) | 3M_7100101327 | Standard | Standard | Standard (ref. 7100101327) | In stock | €48,67 |
Taxes included. Discounts and shipping calculated at checkout.
